Unleashing CMake's Potential: The set_property() Command Explained

CMake is a cross-platform, open-source build system that generates platform-specific makefiles, project files, and IDE code for building, testing, and packaging software. It provides a powerful way to manage the build process across different operating systems and compilers.

set_property() is a versatile command in CMake that allows you to associate named properties with various entities within your project, including:

  • Targets: Executable binaries, libraries, custom commands, etc.
  • Sources: Source files like C++, C, Fortran, etc.
  • Directories: Specific directories within your project.
  • Global (cache entries): Properties that persist across projects and configurations.

The basic syntax of set_property() is as follows:

  • GLOBAL : Sets a property in the global cache that applies to all projects.
  • DIRECTORY [<dir>] : Sets a property in a specific directory or its subdirectories.
  • TARGET [<target1> ...] : Sets a property on one or more targets.
  • SOURCE [<src1> ...] [DIRECTORY <dirs>] : Sets a property on one or more source files.
  • <TARGETS> (optional): One or more target names affected by the property.
  • <DIRECTORIES> (optional): One or more directories where the property applies.
  • PROPERTY <PROPERTY_NAME>: The name of the property to set.
  • <VALUE>: The value to assign to the property.

Common Property Names:

  • COMPILE_FLAGS: Compiler flags applied to source files.
  • LINK_FLAGS: Linker flags applied to targets.
  • SOURCE_FILES: List of source files associated with a target.
  • HEADER_FILES: List of header files associated with a target.
  • EXCLUDE_FROM_ALL: Excludes a target from all build configurations.
  • CXX_STANDARD: Sets the C++ standard for source files (e.g., 11 , 14 , 17 ).

Sample Code:

  • Properties can be strings, lists, or booleans.
  • Use set_property(APPEND) to add values to list-type properties.
  • Use set_property(APPEND_STRING) to concatenate strings to string-type properties.
  • Customizing build behavior
  • Providing information to downstream tools
  • Configuring project-specific settings
  • Incorrect scope or property name
  • Missing or invalid target or source file
  • Attempting to set a property on an inappropriate entity (e.g., setting COMPILE_FLAGS on a target)

Additional Considerations:

  • Refer to the official CMake documentation for a complete list of supported properties and their meanings.
  • Use properties judiciously to avoid cluttering your project and making it harder to maintain.
  • Consider using CMake variables or other mechanisms for configuration options that might change frequently.

By effectively using set_property() , you can enhance the flexibility and control you have over your CMake projects, tailoring them to your specific build requirements.

Set a named property in a given scope.

Sets one property on zero or more objects of a scope.

The first argument determines the scope in which the property is set. It must be one of the following:

Scope is unique and does not accept a name.

Scope defaults to the current directory but other directories (already processed by CMake) may be named by full or relative path. Relative paths are treated as relative to the current source directory. See also the set_directory_properties() command.

New in version 3.19: <dir> may reference a binary directory.

Scope may name zero or more existing targets. See also the set_target_properties() command.

Scope may name zero or more source files. By default, source file properties are only visible to targets added in the same directory ( CMakeLists.txt ).

New in version 3.18: Visibility can be set in other directory scopes using one or both of the following sub-options:

The source file property will be set in each of the <dirs> directories' scopes. CMake must already know about each of these directories, either by having added them through a call to add_subdirectory() or it being the top level source directory. Relative paths are treated as relative to the current source directory.

New in version 3.19: <dirs> may reference a binary directory.

The source file property will be set in each of the directory scopes where any of the specified <targets> were created (the <targets> must therefore already exist).

See also the set_source_files_properties() command.

New in version 3.1.

Scope may name zero or more installed file paths. These are made available to CPack to influence deployment.

Both the property key and value may use generator expressions. Specific properties may apply to installed files and/or directories.

Path components have to be separated by forward slashes, must be normalized and are case sensitive.

To reference the installation prefix itself with a relative path use . .

Currently installed file properties are only defined for the WIX generator where the given paths are relative to the installation prefix.

Scope may name zero or more existing tests. See also the set_tests_properties() command.

Test property values may be specified using generator expressions for tests created by the add_test(NAME) signature.

Scope must name zero or more cache existing entries.

The required PROPERTY option is immediately followed by the name of the property to set. Remaining arguments are used to compose the property value in the form of a semicolon-separated list.

If the APPEND option is given the list is appended to any existing property value (except that empty values are ignored and not appended). If the APPEND_STRING option is given the string is appended to any existing property value as string, i.e. it results in a longer string and not a list of strings. When using APPEND or APPEND_STRING with a property defined to support INHERITED behavior (see define_property() ), no inheriting occurs when finding the initial value to append to. If the property is not already directly set in the nominated scope, the command will behave as though APPEND or APPEND_STRING had not been given.

The GENERATED source file property may be globally visible. See its documentation for details.

  • define_property()
  • get_property()
  • The cmake-properties(7) manual for a list of properties in each scope.

© 2000–2023 Kitware, Inc. and Contributors Licensed under the BSD 3-clause License. https://cmake.org/cmake/help/v3.26/command/set_property.html
